Description
- Compatible with WisuLink wireless interconnected products
- Dual communication based on Ethernet and Wi-Fi
- Support wall mounting or free-standing on the table
- Support OTA software upgrades
- Support 4 LED indicators to illustrate the status of Power, Fault, Alarm and Internet Connectivity
Power Supply: 5.0V/1.0A
Alarm Volume: 70 dB
Alarm Mode: Visual and audible alarm
Indicator Light: Alarm, fault and operation indicator
LED Instructions:
Standby: Green indicator stays on continuously
Pairing: Green indicator flashes quickly (once per 0.5 seconds)
Unpairing: All indicators stay on continuously for 3 seconds
Alarm: Red indicator stays on continuously
Fault: Yellow indicator stays on continuously
Distributed the network successfully: Blue indicator stays on continuously
AP distribution mode: Blue indicator flashes quickly (once per 0.5 seconds)
Reset: Red indicator flashes quickly (once per 0.5 seconds)Wi-Fi Frequency: 2.4 GHz (Incompatible with 5 GHz Wi-Fi network)
Wi-Fi Transmission Range: 50 m (164 ft)
Wi-Fi Protocol: IEEE 802.11b/g/n
Operating Frequency: 868 MHz
Maximum Number of Connected Devices: 24 WisuLink wireless interconnected products
Color: White
Casing: ABS
Dimensions: L78.2mm × W78.2mm × H22.9mm (L3.08″ × W3.08″ × H0.90″)
Weight: 60 g (0.13 lb)
Installation: Free-standing/Wall mounting
Operating Temperature: -10°C to +55S°C (+14°F to +131°F)
Operating Humidity: ≤95% RH (non condensing)
Certifications: CE, UKCA
